10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials

Product Details

Place of Origin: Shanghai, China

Brand Name: Focusun

Certification: CE

Payment & Shipping Terms

Minimum Order Quantity: 1pc

Price: $20,000.00/sets 1-1 sets

Packaging Details: standard wood packages and transport in container

Supply Ability: 100 Set/Sets per Quarter

Get Best Price
Highlight:
Applicable Industries:
Food & Beverage Factory, Retail, Food Shop, Food & Beverage Shops
Condition:
New
Ice Shape:
Flake Ice
Voltage:
380v/50hz/3p
Power:
42kw
Dimension(L*W*H):
3550*1550*2100 Mm
Weight:
2200kg
Warranty:
15months
Key Selling Points:
High Productivity
Ice Storage Capacity:
Other
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
3 Years
Core Components:
PLC
Name:
10 Ton Fresh Water Flake Ice Machine
Compressor:
Bitzer
Application:
Seafood
Cooling Way:
Water Cooling
Refrigerant:
R404A Or R22
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Keyword:
Flake Ice Machine
Material:
Stainless Steel 304
Ice Size:
40*40mm
Type:
Automatic Flake Ice Machine
After Warranty Service:
Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location:
None
Showroom Location:
None
Marketing Type:
Hot Product 2019
Port:
Shanghai Port
Applicable Industries:
Food & Beverage Factory, Retail, Food Shop, Food & Beverage Shops
Condition:
New
Ice Shape:
Flake Ice
Voltage:
380v/50hz/3p
Power:
42kw
Dimension(L*W*H):
3550*1550*2100 Mm
Weight:
2200kg
Warranty:
15months
Key Selling Points:
High Productivity
Ice Storage Capacity:
Other
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
3 Years
Core Components:
PLC
Name:
10 Ton Fresh Water Flake Ice Machine
Compressor:
Bitzer
Application:
Seafood
Cooling Way:
Water Cooling
Refrigerant:
R404A Or R22
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Keyword:
Flake Ice Machine
Material:
Stainless Steel 304
Ice Size:
40*40mm
Type:
Automatic Flake Ice Machine
After Warranty Service:
Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location:
None
Showroom Location:
None
Marketing Type:
Hot Product 2019
Port:
Shanghai Port
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials
Our Company
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 0

Focusun is the pioneer in ice cooling technology, design & manufacture. Focusun's headquarter is located in Shanghai city, production and R&D team is located in Taizhou city, Jiangsu pro-vince, with more than 35,000 square meters of standardized modern plant. Our main products include all kinds of ice plant, such as block ice plant, tube ice plant, flake ice plant, cube ice plant,plate ice plant.

We produce almost all ice making machine, having providing ice machine and cooling system for over 150 countries and areas. There must be one product suits your business!

Professional sales teams combined with excellent working experience production. Bring products from factory directly to you, saving the cost of different marketing channels.

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 1
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 2
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 3
Product Description
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 4
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 5

FLAKE ICE MACHINE

Scale Ice Machine/Flake Ice Machine
The multiple applications of this type of ice from the industry to the hotel industry, with any configuration: compact machine. Remote group or connected to central cold.
Acquiring a flake ice machine benefits from the support of the best team of ice experts: It is a machine designed to make 100% ice water.
This product on the inside of the evaporator, vertical cylindrical. Made of steel, with an internal labyrinth for the circulation of the refrigerant. Which is isolated to avoid loss of performance of the machine. The inner face is nickel-plated, and has an outer stainless steel jacket.
Scale ice is usually large, flat, thin pieces of ice (1-2 mm) mainly used in the commercial fishing and concrete cooling industries, typically in large quantities.
Made on a large vertical or horizontal drums, scale ice is formed on either the inner or outer surface of the drum by pouring a film of water over it, then contact freezing it into a thin sheet of ice. This ice is subcooled down to -7°C in order to make it brittle, then cracked off by a harvesting blade. The ice then falls by gravity into the ice store. These large, flat
pieces are good for layering, and are available with a single evaporator up to 50 tonnes.
The vertical style of drum is usually stationary, with the ice formed on the inner surface. The harvesting blade is motor driven around this surface, cracking it off. The horizontal style of drum is usually rotating, with the ice formed on the outer surface. As the drum rotates, a stationary blade cracks the ice from the surface

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 6
SPECIFICATIONS FOR 10 TON Fresh Water Flake ice Machine

Compressor
Manufacturer
Available brands
Bitzer / Copealand/ Bock
Compressor COP/EER
Kw
2
Horse Power
KW
25 X 2SETS
Dimension
Size of Ice Maker
L×W×H(mm)
3550×1550×2100
Size of Cooling Tower
L×W×H(mm)
¢1580×2205
Size of Ice Outlet
mm
¢2160
Weight
Weight of Flake Ice Maker
kg
2200
Operating Weight of Cooling Tower
kg
540
Water supply pressure requirement
bar
1~6
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 7
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 8
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 9
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 10

Main Features

Power Configuration: Standard power is 380V/3P/ 50Hz. The electrical system can be adjusted according to actual situation and should be confirmed when ordering.

Unit Configuration: Copeland ful-hermetic piston compressor and air-cooling condenser;

Once provided water and power in scene, the flake ice maker can be put into operation immediately.

Refrigerant Configuration: New type of environmental friendly refrigerant R404A;

Ice Storage Configuration: Each ice flake maker is equipped with stainless steel ice storage with certain c
apacity.

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 11
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 12
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 13
Detailed Images
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 14

Machine Parts

Name: Fresh water Flake ice machine/ Scale Ice Making Machines

Brand: FOCUSUN

Original: Germany

Germany Bitzer compressor, Siemens PLC, Schneider electric, Danfoss valves, etc all are famous suppliers.

Main Features

Internally-scraping ice skate can help reduce energy consumption and prevent leakage of refrigerant.

Stainless steel materials,advanced processing equipment and heat treatment processing ensure the best heat transfer efficiency.

The design of large water receiving plate can prevent water leaking at the bottom of evaporator.

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 15
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 16

Machine Application

It is mainly used in the fishing industry, particularly by processors with large ice requirements, and in the concrete industry where huge volumes are often required in hot climates, thus requiring cold storage.

Main Features

Irregular ice flakes with size about 40*40mm and thickness around 1.5-2.5 mm.

The thin ice can be directly used for stirring and mixing refrigerated materials.

No accurate edges and corners so it will not damage the surface of the cooled object.

Large contact area and fast cooling speed.

Easy to crush and mold.

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 17
Our Service
10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 18

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.




Also other products:
Focusun flake ice plant series: http://www.flake-ice-plant.com/
Focusun tube ice plant series: http://www.tube-ice-plant.com/
Focusun block ice plant series: http://www.block-ice-plant.com/
If you are considering to purchase an block ice machine, or you are just want to know information about the block ice machine and prepare your business for future, please feel free to contact Focusun sales team.

To make customer have better understanding, our Focusun company launched a new website and totally explains the different block ice machines. Can you visit here : http://www.block-ice-plant.com


We are very interested to have your inquiry.
We are looking forward to give our best supports.
We are also welcome your visit to FOCUSUN CHINA FACTORY to have face-to-face meeting with our engineering
team.

10 Ton Flake Ice Machine for Direct Slicing and Combining Refrigerated Materials 19

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.



Packing & Delivery

PACKING DETAILS

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
